General

• Total Fuel Capacity: 3.5 gallons (36″ and 42″)
  5.5 gallons (48″, 52″ and 61″)
• Drive Tires: 20″ x 8″-10″ (36″)
  20″ x 10″-8″ (42″, 48″ and 52″)
  20″ x 10″-10″ (61″)
• Caster Tires: 11″ x 4″-5″ (36″ and 42″)
  11″ x 6″-5″ (48″, 52″ and 61″)
• Seat: Padded with arm rests, adjustment forward and back (tools required)
  (No armrests on 36″ and 42″ models)

Drive System

• Drive System Type: 36″ and 42″ models: Hydro-Gear ZT-2800 Transaxle
  48″, 52″ and 61″ models: Tuff Torq TZ450 Transaxle
• Pumps: Internal Pump – 10 cc
• Motors: Internal Motor – 10cc (Tuff Torq), 16 cc (Hydro-Gear)
• Forward Ground Speed: 7 mph
• Reverse Ground Speed: 5 mph
• Parking Brake: Hand lever

Deck

• Cutting Widths: 36″, 42″, 48″, 52″ and 61″
• Cutting Height: 1.5″ to 4.5″ in 0.25″ increments
• Spindles: Aluminum housing with sealed ball bearings
• Construction: Dual-plate cutter deck constructed of 2 steel plates. Reinforcement plate at cutter deck spindles.
• Deck Lift: Foot-operated pedal
• Type: Heavy-Duty Hero Cutter Deck
• Blade Engagement: Ogura GT1 (74 ft lb) – (36″, 42″, 48″ and 52″)
  Ogura GT2 (108 ft lb) – (61″)
  Adjustable air-gap for extended life.
