Features –
-
- Dual-stage, track drive, clears a 55 cm (21.7 in.) width
- 2-speed forward transmission plus reverse
- Worklight
- Honda GX160T2, OHV, 4-stroke engine
- Handlebar mount remote throttle and choke controls
| Discharge Type | Dual-stage | ||
|---|---|---|---|
| Axle Type | Track drive | ||
| Drive Type | Gear mesh transmission | ||
| Transmission Oil Capacity | N/A | ||
| Hydrostatic Transmission | N/A | ||
| Speeds | 2 forward / 1 reverse | ||
| Clearing Width | 55 cm (21.7 in.) | ||
| Maximum Ground Speed | Forward (1): 22.2 m/min (72.8 ft./min) | Forward (2): 52.8 m/min (173.2 ft./min) | Reverse: 51 m/min (167.3 ft./min) |
| Intake Housing Height | 42 cm (16.5 in.) | ||
| Auger Diameter | 30.5 cm (12 in.) | ||
| Auger Type | Steel | ||
| Auger Drive | Dry; multi-disc clutch | ||
| Auger Transmission | Screw gear | ||
| Auger Oil Capacity | 0.16 Litre (5.6 fl. Imp. oz.) | ||
| Auger gear box | SAE #90 gear oil | ||
| Auger Height Adjustment | 3 position adjuster | ||
| Chute Turning Radius | 195° | ||
| Chute Rotation | Manual lever | ||
| Deflection Control | Manual lever | ||
| Chute Material | Steel | ||
| Maximum Throw Distance† | 14 m (46 ft.) | ||
| Clearing Snow Volume Capacity (Approximate)† | Up to 37 metric tons/hr (41 tons/hr) |
| Engine Type | Honda GX160T2, 4-stroke, OHC, single-cylinder |
|---|---|
| Displacement | 163 cc (9.9 CID) |
| Ignition System | Transistorized |
| Recoil Starter | Standard (Back-up) |
| Electric Starter | Standard 12 VDC type (Battery) |
| Lubrication System | Forced splash |
| Oil Capacity | 0.58 Litre (20.4 fl. Imp. oz.) |
| Oil for engine | SAE 5W30 API service classification SJ or later |
| Recommended Fuel | Regular unleaded gasoline (87 Octane) |
| Fuel Tank Capacity | 3.1 Litres (0.68 Imp. gal.) |
| Operational Time per Tankful* | 2.7 hours |
| Wheel/Tire Size | N/A |
|---|---|
| Overall Length | 145.5 cm (57.3 in.) |
| Overall Width | 56.5 cm (22.2 in.) |
| Overall Height | 115 cm (45.3 in.) |
| Dry Weight | 75 kg (165 lbs.) |
| Lighting Coil | Standard |
| Work Light | Standard |
| Distributor’s Warranty (non-commercial use) |
36-month |
|
Distributor’s Warranty (commercial use) |
36-month |
