Description
Highlights –
- Weighs only 20 lbs.
- 74 gal./min capacity
- Hose clamps and strainer included
Features –
-
- Perfect for homeowners, gardeners, boat owners, and more
- Easy starting Honda mini 4-stroke commercial engine
- Lightweight aluminum pump
- Hose clamps and strainer included
- Standard transport handle
- 74 gal./min capacity
- Protected by Honda Oil Alert
|
Engine |
GXH50 | ||
|
Displacement |
49cc | ||
|
Bore and stroke |
1.65" x 1.42" | ||
|
Compression Ratio |
8.0:1 | ||
|
Oil Alert |
Std | ||
|
Pump Type |
General purpose Centrifugal Self-priming | ||
|
Volute |
Aluminum | ||
|
Impeller |
Aluminum | ||
|
Mechanical Seal (Pump case / impeller) |
Carbon/Ceramic | ||
|
Priming time |
120 sec. at 16.4 ft. | ||
|
Drive system |
Direct | ||
|
Discharge capacity |
74 gal/min | ||
|
Suction port diameter |
1.5" NPT | ||
|
Discharge port diameter |
1.5" NPT | ||
|
Total head lift |
121 ft. | ||
|
Suction head lift |
26 ft. | ||
|
Maximum pressure |
52 psi | ||
|
Solids handling |
N/A | ||
|
Dimensions (LxWxH) |
14.0"x10.8"x14.8" | ||
|
Dry weight20 |
lb. | ||
| Fuel Capacity | 0.20 gal | ||
| Run Time @ Max Discharge | 0.9 hr | ||
| Strainer Part | #78325-YB0-751 | ||
| Residential Warranty | 2 years | ||
| Commercial Warranty | 1 year | ||
| CA Compliant | Yes |
