Description
Highlights –
- Drive Type- Hydrostatic transmission (HST) with Steering Assist Drive
- Starter- Standard electric & recoil (Back-up)
- Clearing Width- 60.5 cm (23.8 in.)
- Tons per hour- Up to 42 metric tons/hr (46 tons/hr)
Features –
- 12 VDC electric start with manual recoil as backup
- Remote electric two-step chute with “joystick" control
- Dual-stage, track drive, 60.5 cm (23.8 in.) clearing width
- Clear up to 42 metric tons (up to 46 tons) of snow per hour† and throw it up to 15 m (49.2 ft.)†
- Discharge Type
- Dual-stage
- Axle Type
- Track drive
- Drive Type
- Hydrostatic transmission (HST)
- Transmission Oil Capacity
- 1.9 Litre
- Speeds
- Infinitely variable
- Clearing Width
- 60.5 cm (23.8 in.)
- Maximum Ground Speed
- Forward: 60 m/min. (196.9 ft./min)
Reverse: 48 m/min. (157.5 ft./min)
- Intake Housing Height
- 55 cm (21.7 in.)
- Auger Diameter
- 35.5 cm (14 in.)
- Auger Type
- Steel serrated (Spiral)
- Auger Drive
- Belt driven shaft
- Auger Transmission
- Screw gear
- Auger Oil Capacity
- 0.16 Litre (5.6 fl. Imp. oz.)
- Auger Height Adjustment
- Gas assist
- Chute Turning Radius
- 198 ° (95° Left, 103° Right)
- Chute Rotation
- Remote electric “Joystick” control
- Deflection Control
- Remote electric “Joystick” control
- Chute Material
- Steel
- Maximum Throw Distance†
- 15 m (49.2 ft.)
- Clearing Snow Volume Capacity (Approximate)†
- Up to 42 metric tons/hr (46 tons/hr)
- Engine Type
- Honda GX200T2, 4-stroke, OHV, single-cylinder
- Displacement
- 196 cc (12.0 CID)
- Ignition System
- Transistorized
- Recoil Starter
- Standard (Back-up)
- Electric Starter
- Standard 12 VDC type
- Lubrication System
- Forced splash
- Oil Capacity
- 0.60 Litre (21.1 fl. Imp. oz.)
- Recommended Oil
- SAE 5W30 API service classification SJ or later
- Recommended Oil
- SAE 75W90 GL-5
- Recommended Oil
- SAE 5W30 API service classification SJ or later
- Recommended Fuel
- Unleaded gasoline (Pump octane rating 86 or higher)
- Fuel Tank Capacity
- 3.1 Litres (0.68 Imp. gal.)
- Operational Time per Tankful*
- 2 hours
- Wheel/Tire Size
- N/A
- Overall Length
- 148.5 cm (58.5 in.)
- Overall Width
- 63 cm (24.8 in.)
- Overall Height
- 123 cm (48.4 in.)
- Dry Weight
- 115 kg (253.5 lbs.)
- Lighting Coil
- Standard
- Work Light
- Standard
- Distributor’s Warranty (non-commercial use)
- 36-month
- Distributor’s Warranty (commercial use)
- 36-month
