Description
- Generator Type
- Brush type
- Maximum AC Output (Watts)
- 5,000
- AC Voltage Available
- 120 / 240
- Maximum Continuous AC Output (Watts)
- 4,500 7,000 (iAVR)
- Max. Rated AC Amperage @ 120 V / 240 V
- 37.5 / 18.8 (58.3 / 29.2 for 10 sec. iAVR)
- Ground Fault Circuit Interrupter (GFCI)
- N/A
- Frequency (Hertz)
- 60
- Automatic Voltage Regulator
- Standard iAVR (Intelligent Automatic Voltage Regulator)
- DC Output Volts / Amps
- 12 / 8
- Common Duplex Receptacle Specifications
- 37.5 amps/120 VAC continuous is available as combined total from these twin duplex AC receptacles.
- DC Receptacle Specifications
- 8 amps/12 VDC is available from these +/- thumb screw terminals. Important Note: AC and DC output can be used simultaneously on this series only. DC system uses floating N (Neutral) type.
- DC Charging Cable
- Optional (P/N 32650-825-015)
- High Capacity 120 / 240 VAC Twist Lock Receptacle Specifications
- This receptacle (NEMA # L5-30R) will supply 30 amps at 120 VAC continuously. This receptacle (NEMA # L14-30R) will supply 18.8 amps (4.5 kVA) at 240 VAC continuously.
- Engine Type
- Honda iGX390T2 OHV, 4-stroke, air-cooled
- Displacement
- 389 cc
- Starting System
- Electric/recoil
- Low Level Oil Alert System
- Standard
- Auto Throttle
- Standard
- Remote Start Capability
- Optional
- Fuel Tank Capacity
- 23.5 litres (5.17 Imp. gal.)
- Transport Wheels
- 2 Wheel standard
- Lifting Hook
- Optional (P/N 06810-Z22- A30ZA)
- Battery
- Standard (P/N 31500-MCR-J01)
- Approximate Running Time (hrs.) / Tankful
- 8.1** / 11.2****
- Rated Fuel Consumption (litres/hr)
- 2.90**
- Noise Level dB(A) (1.5 m to 7 m)
- 72**
- Length (Without Handles and Wheels)
- 681 mm (26.8 in.)
- Length (With Handles and Wheels)
- 1,043 mm (41.1 in.)
- Width (Without Handles and Wheels)
- 530 mm (20.9 in.)
- Width (With Handles and Wheels)
- 706 mm (27.8 in.)
- Height (Without Lift-Hook)
- “719 mm (28.3 in.)
- Height (With Lift-Hook)
- 773 mm (30.4 in.) optional lift hook
- Dry Weight
- 102.2 kg (225.3 lbs.)
- Cold Climate Technology
- Standard
